Visually Graded Lumber vs. Machine Graded Lumber

Visually Graded Lumber vs. Machine Graded Lumber

There are different ways of determining the grade of dimension lumber. Historically, “visual” grading is performed where a person looks at all four sides of a piece of lumber and evaluates the characteristics present to determine which of several visual grades the piece belongs. This grader works on a grading chain and quickly evaluates each piece of lumber.

Visual grading rules have been written that define what size characteristics are permitted in each grade. Characteristics evaluated include both strength-reducing characteristics such as knots, slope of grain, and holes, as well as appearance and/or serviceability characteristics such as wane, skipped dressing, warp, etc. These pictures show some of the various appearance and strength-reducing characteristics that are limited in each grade:

In fact, for common grades of dimension lumber (2”-4” thick, 2”-12”+ wide), there is a National Grading Rule which applies to all species of structural lumber. This was originally designed so that lumber of the same visual grade would have the same appearance. In reality, because species of lumber have different inherent characteristics, a piece of #2 2×4 southern pine will not necessarily have the same appearance as a #2 2×4 hem-fir. Furthermore, because the inherent strength of species varies, a piece of #2 2×4 southern pine does not have the same design values as a #2 2×4 of another species. This results in a system where each species, size, and grade of dimension lumber has different design values.

A second way of determining the grade of dimension lumber involves “machine” grading. In this situation, a machine that has been approved by the American Lumber Standard Committee is used to evaluate one or more specific characteristics that are related to the strength and stiffness of the lumber. Initial machines deflected the piece and measured the force required to bend the piece a specified amount. This force can be used to calculate a stiffness value for the piece and strength is related to stiffness. A system of grades was developed called “machine stress rated lumber” or MSR. The lumber is sorted into the appropriate MSR grade by the machine. Because original machines were not able to evaluate various other characteristics, a visual override also needed to be applied, primarily to evaluate appearance attributes. The grades of MSR are designated by an “fb-E” rating. For example, one common MSR grade is 2400fb-2.0E, meaning the bending design value assigned is 2400 psi and the stiffness value assigned in 2.0 million psi. This also means that any species of MSR with a 2400f-2.0E rating has these design values assigned to it. However, it should be noted that design values for other properties, such as tension, compression, shear, etc. may still vary by species even though the bending strength and stiffness are the same for all species of a particular MSR grade. Here are some sample MSR grademarks:

As technology has advanced, some companies have developed “visual grading machines”. That is, with a system of scanners, lasers, and other technology, the visual grading parameters present in a piece of lumber can be evaluated and compared to required characteristics. The piece can then be assigned to a visual grade of lumber without a human specifically looking at the piece. The system may or may not attempt to take into account the predicted strength of a board, but is simply applying the very specific visual grading rules.

As you can imagine, the two types of grading machines are often combined. One machine may evaluate a property related to strength characteristics, such as stiffness, density, etc. and a second machine may use photos, lasers, or scanners to evaluate the “visual” characteristics. Trained human graders have a long successful history of quickly and accurately evaluating lumber and assigning it to a specific grade. But as production at large mills continues to increase, it gets harder to train and retain accurate human graders. Once properly programmed, machines are able to accurately sort lumber in various grades and are becoming more and more common.
